032920S-AUXILIARY BOILER

FOR AUXILIARY BOILER / SHIP NO: 21N1649 PRESS. SWITCH DANFASS CUT IN -0.2 - 7.5 BAR PE DIFF 4-0.7

DANFOSS.NA.NA

MANHOLE PACKING  Draw. No： 52-CO-479D

MIURA CO., LTD..GK-2230-1000/1000.A524-117-4020-0

WIND BOX PACKING (INSIDE 1.94M)  Draw. No： 52-CO-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2859-0MANHOLE PACKING  Draw. No： 52-CO-479D

MIURA CO., LTD..GK-2230-1000/1000.A524-117-4020-0

WIND BOX PACKING (INSIDE 1.94M)  Draw. No： 52-CO-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2859-0

WIND BOX PACKING (OUTSIDE 2.06M)  Draw. No： 52-CO-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2862-0

SHROUD WITH BAFFLE PLATE  Draw. No： 52-C0-479D

PART:A524-327-0004-4

(A524-310-6011-0)

MIURA CO., LTD..GK-2230-1000/1000.A524-327-0004-4

NOZZLE TIP WITH CUT-OFF VALVE (7.0G- MAIN)  Draw. No： 52-C0-479D

PART:0509-400-0700-0(0000-AA6-2660-0)

MIURA CO., LTD..GK-2230-1000/1000.0509-400-0700-0

NOZZLE TIP WITH CUT-OFF VALVE

(2.0G PILOT)  Draw. No： 52-C0-479D

PART:0509-600-0200-0

(0190-051-0010-0)

MIURA CO., LTD..GK-2230-1000/1000.0509-600-0200-0

GLASS FOR PEEP HOLE COVER  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.00065-029-3000-0

PACKING FOR PEEP HOLE COVER  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-00S-2976-0

SPARK ROD  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.A524-318-4000-0

LEAD INSULATOR  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0881-102-0000-0

FLAME EYE  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0807-230-0040-0

INSULATOR CAP  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0085-000-0000-0

SOLENOID VALVE FOR MAIN (100V)  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-1610-0

FLEXIBLE TUBE WITH COUPLER

(3/8Bx600L, NK)  Draw. No： 52-C0-631

PART NUMBER:(0000-AA7-3820-0+

0000-AA7-3659-0+

0000-AA7-3660-0)

MIURA CO., LTD..GK-2230-1000/1000.(0000-AA7-3820-0

GAUGE GLASS ASSEMBLY  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AKZ-3725-0

ELECTRODE HOLDER (L=100MM)  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0840-200-0013-0

RELAY  Draw. No： 52-D0-396A

MIURA CO., LTD..GK-2230-1000/1000.0000-AA8-2764-0

RELAY  Draw. No： 52-C0-479D

MIURA CO., LTD..GK-2230-1000/1000.0000-AKB-5026-0

MANHOLE PACKING

(500A- 545MM DIA.)  Draw. No： 52-C0-636

MIURA CO., LTD..GK-2230-1000/1000.A524-118-8000-0

HANDHOLE PACKING (390x290MM)  Draw. No： 52-C0-636

MIURA CO., LTD..GK-2230-1000/1000.A214-102-9A10-0

BEARING BUSH (F.O.BOOSTER PUMP)  Draw. No： A694-169-7030 (A694-169-6010)

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2301-0(3B)

BEARING BUSH (F.O.BOOSTER PUMP)  Draw. No： A694-169-7030 (A694-169-6010)

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2301-0(3A)

GLAND PACKING (F.O.BOOSTER PUMP)  Draw. No： A694-169-7030 (A694-169-6010)

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2310-0(08)

VALVE SPRING (F.O.BOOSTER PUMP)  Draw. No： A694-169-7030 (A694-169-6010)

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2313-0(24)

SPACER (F.O.BOOSTER PUMP)  Draw. No： A694-169-7030 (A694-169-6010)

MIURA CO., LTD..GK-2230-1000/1000.0000-AA7-2754-0(97B)

BALL BEARING-D-END

(F.O.BOOSTER PUMP/ F.O. PUMP MOTOR)  Draw. No： A694-169-7030

MIURA CO., LTD..GK-2230-1000/1000.0000-000-H565-0

BALL BEARING-N-END

(F.O.BOOSTER PUMP/ F.O. PUMP MOTOR)  Draw. No： A694-169-7030

MIURA CO., LTD..GK-2230-1000/1000.0000-AKZ-0067-0

PRESSURE GAUGE: BVU3/8xø75x0,6MPa  Draw. No： A694-230-1000 (3/3)

MIURA CO., LTD..GK-2230-1000/1000.NA

PRESSURE GAUGE: BVU3/8xø75x0,6MPa  Draw. No： A694-230-1000 (3/3)

MIURA CO., LTD..GK-2230-1000/1000.NA

PUMP SHAFT WITH GEAR (F.O.BOOSTER PUMP)  Draw. No： A694-230-1000 (2/3)

MIURA CO., LTD..GK-2230-1000/1000.05A

PUMP SHAFT WITH GEAR (F.O.BOOSTER PUMP)  Draw. No： A694-230-1000 (2/3)

MIURA CO., LTD..GK-2230-1000/1000.05B

KEY FOR COUPLING  Draw. No： A694-230-1000 (2/3)

MIURA CO., LTD..GK-2230-1000/1000.K12

MAKER:MIURA CO., LTD

TYPE:VERTICAL WATER TUBE COMPOSITE BOILER, GK-2230-1000/1000

PRESSURE GAUGE: BVU3/8xø75x0,6MPa  Draw. No： A694-230-1000 (3/3)

MIURA CO., LTD..GK-2230-1000/1000.NA
