033057C-TANABE.H-264

FOR MAIN AIR COMPRESSOR VALVES

MAKER:TANABE

MODEL:H-264

VERTICAL TYPE, WATER COOLED, 2 STAGE COMPRESSOR

1ST STAGE AIR VALVE: VZ-6100/                   2ND STAGE AIR VALVE: VP-2700

1ST STAGE AIR VALVE: VZ-6100，DWG NO.: A3-4040VALVE SEAT GASKET (COPPER)DWG NO:A3-6109

TANABE.H-264.1

NUT

TANABE.H-264.2

VALVE SEAT

TANABE.H-264.3

DISK

TANABE.H-264.4

VALVE SPRING

TANABE.H-264.5

VALVE PLATE (SUCTION.2)

TANABE.H-264.6

VALVE PLATE (SUCTION.3)

TANABE.H-264.7

VALVE SPRING (SUCTION.1)

TANABE.H-264.8

VALVE SPRING (SUCTION.2)

TANABE.H-264.9

VALVE SPRING (SUCTION.3)

TANABE.H-264.10

LP VALVE DISK

TANABE.H-264.11

VALVE GUARD (DELIVERY)

TANABE.H-264.12

OIL FILTER ELEMENT ASSEMBLY(FO-600)DWG NO: S4-8424

TANABE.H-264.13

H.P DISK

TANABE.H-264.14

WATER CHECKER (SIGHT GLASS)DWG NO: G2 -8744

TANABE.H-264.15

VALVE SPRING (DELIVERY.2)

TANABE.H-264.16

SCREW

TANABE.H-264.17

GUIDE RING

TANABE.H-264.18

VALVE SEAT GASKET(IN SIDE)DWG NO: A3-4040

TANABE.H-264.19

VALVE SEAT GASKET(OUT SIDE)DWG NO: A3-4040

TANABE.H-264.20
