062520W- Fire protection system

产品分类：SPARE PARTS FOR MAIN& AUJXILIARY

"FOR DECK - FIXED CO2 FIRE EXTINGUSHER SCAVENGE & GALLEY ### REQUIRED HOSES FOR 10 YEARLYINSPECTIONSEAPLUS - PM01155 & CH02D02" "FLEXIBLE HOSE,HIGH PRESSURE, CO2FOR GALLEY FIXED CO2 FIRE EXTINGUSHE···

订购热线：+86 13303352133

Immediately consult

product details

"FOR DECK - FIXED CO2 FIRE EXTINGUSHER SCAVENGE & GALLEY ### REQUIRED HOSES FOR 10 YEARLYINSPECTION

SEAPLUS - PM01155 & CH02D02" "FLEXIBLE HOSE,HIGH PRESSURE, CO2

FOR GALLEY FIXED CO2 FIRE EXTINGUSHER

HIGH PRESSURE HOSE - WIRE BRAIDED RUBBER / DN: 12 / O.D: 20.1MM / ROD: 18.1MM

END COUPLING NUTS - MILD STEEL WITH ELEC. GALVANIZED

HOSE CONNECTORS - MILD STEEL WITH ELEC. GALVANIZED

HYD. TEST PRESSURE : 245 KG/CM2 (24 MPA)

BURST PRESSURE : 652 KG/CM2 (64 MPA)

MAX. WORKING PRESSURE: 163 KG/CM2(16 MPA)

MAX. WORKING RANGE: -40·C ~ +100·C

LENGTH :850MM

AS PER ATTCHED PLAN NO 01 & 04" SEAPLUS CO ., LTD.CH02D02.CH-1220-00-GALLEY (B-5)

"FOR DECK - FIXED CO2 FIRE EXTINGUSHER SCAVENGE & GALLEY ### REQUIRED HOSES FOR 10 YEARLYINSPECTION

SEAPLUS - PM01155 & CH02D02" "FLEXIBLE HOSE,HIGH PRESSURE, CO2 FOR ENG ROOM FIXED CO2 FIRE EXTINGUSHER

HIGH PRESSURE HOSE - WIRE BRAIDED RUBBER / DN: 12 / O.D: 20.1MM / ROD: 18.1MM

END COUPLING NUTS - MILD STEEL WITH ELEC. GALVANIZED

HOSE CONNECTORS - MILD STEEL WITH ELEC. GALVANIZED

HYD. TEST PRESSURE : 245 KG/CM2 (24 MPA)

BURST PRESSURE : 652 KG/CM2 (64 MPA)

MAX. WORKING PRESSURE: 163 KG/CM2(16 MPA)

MAX. WORKING RANGE: -40·C ~ +100·C

WEIGHT APPROX. 0.55KG

LENGTH :450MM

AS PER ATTCHED PLAN NO 02 & 05" SEAPLUS CO ., LTD.CH02D02.CH-1220-00-E/R (B-3)

"FOR DECK - FIXED CO2 FIRE EXTINGUSHER SCAVENGE & GALLEY ### REQUIRED HOSES FOR 10 YEARLYINSPECTION

SEAPLUS - PM01155 & CH02D02" "FLEXIBLE HOSE W. FLANGE ,HIGH PRES, CO2 FOR ENG ROOM FIXED CO2 FIRE EXTINGUSHER

HIGH PRESSURE HOSE - WIRE BRAIDED RUBBER / DN: 12 / O.D: 20.1MM / ROD: 18.1MM

END COUPLING NUTS - MILD STEEL WITH ELEC. GALVANIZED

HOSE CONNECTORS - MILD STEEL WITH ELEC. GALVANIZED

HYD. TEST PRESSURE : 161 KG/CM2 (15.8 MPA)

BURST PRESSURE : 560 KG/CM2 (54.9 MPA)

MIN BENDABL RADIUS : 178 MM

MAX. WORKING PRESSURE: 107 KG/CM2(10.5 MPA)

MAX. WORKING RANGE: -40·C ~ +100·C

WEIGHT APPROX. 0.75 KG

LENGTH :450MM

AS PER ATTCHED PLAN NO 03 & 05" SEAPLUS CO ., LTD.CH02D02.CH-1220-00-E/R (B-8)
