062793V-DONGHWA

产品分类:SPARE PARTS FOR MAIN& AUJXILIARY

"Equipment: Main Engine FW cooling systemME FW Jacket PreheaterMaker: DongHwa EntecSerial No: E20410-AAdress: www.dh.co.krRequired part: Tube sheet complete(with heating tubes)quantity required: 1 pc.Additional deta···

订购热线:+86 13303352133

Immediately consult
product details

"Equipment: Main Engine FW cooling system

ME FW Jacket Preheater

Maker: DongHwa Entec

Serial No: E20410-A

Adress: www.dh.co.kr

Required part: Tube sheet complete

(with heating tubes)

quantity required: 1 pc.

Additional details:

Shell Side

Fluid ............. Steam

Flow Qty .......... 320.1kg/hr

operating Press ... 6kg/cm2G

Inlet Temp ........ 164.2oC

outlet Temp ....... 164.2oC

No. of Pass ....... 1

Design Press ...... 7kg/cm2G

Hydraulic Test Press .. 10.5kg/cm2G


Tube Side

Fluid ............  FW

Flow Qty ......... 9.3m3/hr

operating Press .. 4kg/cm2G

Inlet Temp ....... 43oC

outlet Temp ...... 60oC

No. of Pass ....... 2

Velocity .......... 0.987m/sec

Press Drop  ....... 0.1kg/cm2G

Design Press ...... 5kg/cm2G

Hydraulic Test Press .... 7.5kg/cm2G

Surface Area ...... 1m2

Fouling Margine ... 85percent

Joint Efficiency .. 60percent

Weight

Empty ............. 200kg

Full .............. 200kg" TUBE SHEET D=320XT20 DONGHWA ENTEC.NA.DHFH-039913/7


purchase:062793V-DONGHWA
