current location：首页 >> Product >> SPARE PARTS FOR MAIN& AUJXILIARY

013154L-FUNDHEMAR

产品分类：SPARE PARTS FOR MAIN& AUJXILIARY

"NAME:Thrust System/ ShaftsMAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Gasket Propeller Shaft, BAUSpare Parts for The Propeller InstallationDamen system code ···

订购热线：+86 13303352133

Immediately consult

product details

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Gasket Propeller Shaft, BAU

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E" FUNDHEMAR.NA.1008474

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Plain Bearing (Item 016) In Accordance With Drawing 503158-213-651 Rev.-

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E

Fore Bearing

New Damen Part No. 1010220 (Old Damen Part No.1176561)

D=124 x 90.45, L=110

Shaft Dp=90

Bronze RG12" FUNDHEMAR.NA.1010220

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Plain Inter. Bearing (Item 017) In Accordance With Drawing 503158-213-651 R

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E

Intrm Bearing

New Damen Part no. 1010252 (Old Damen Part No.1176562)

D=117 x 90.55, L=70

Shaft Dp=90

Bronze RG12" FUNDHEMAR.NA.1010252

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Aft Bearing (Item 018) In Accordance With Drawing 503148-213-651 Rev.-

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E

Damen Part no.1176563

Aft Bearing, grease

Intrm Bearing

Shaft Dp=90

Bronze RG12" FUNDHEMAR.NA.1176563

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Gasket Propeller Shaft, BAU

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E

D : 175, T: 3 mm, PCD: 145, 8x Holes 11 mm" FUNDHEMAR.NA.1346291

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Propeller shaft seal, Cast Iron

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E" FUNDHEMAR.NA.1009937

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Ring , Rubber, Dp-90, Accord.to Drawing 503158-213-649

Spare Parts for The Propeller Installation

Damen system code 213

Criticality Group PRIME MOVER

Annex E

Rubber

Dp=90

Dim : 125 x 92 x 30 mm

60° Shore" FUNDHEMAR.NA.1046154

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Rudder bearing, Step bearing (006-01)

Plain Bearing, ds:70mm, di:71.5 mm, OD: 130 mm, L: 110 mm

Steel S355J2+N" FUNDHEMAR.NA.1011502

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Rudder Bearing, Upper trunk bearing (007-01)

Plain Bearing, ds:70mm, di : 70 mm, OD: 98 mm, L: 50 mm

Cast Iron" FUNDHEMAR.NA.1011504

"NAME:Thrust System/ Shafts

MAKER:FUNDHEMAR S.L(GAJANO (CANTABRIA)-ESP)

SOLID PROPELLER MADE ON Cu-1 ALLOY (Mn-Brass)" "Rudder bearing, Lower trunk bearing (008-01)

Plain bearing , ds: 70 mm, di: 70 mm, OD: 98 mm, L: 70mm

Cast Iron

Drawing No. 599900-221-647-E" FUNDHEMAR.NA.1011505

purchase：013154L-FUNDHEMAR
